购买 QD ADM2687EBRIZ OPTOISO 5KV TRANSCEIVER 16SOIC

图片可能具有代表性。
产品详情请参阅规格.

数据表

ADM2687EBRIZ

OPTOISO 5KV TRANSCEIVER 16SOIC

型号

ADM2687EBRIZ

制造商/品牌

系列

isoPower®

零件状态

Active

包装

Tube

技术

Magnetic Coupling

工作温度

-40°C ~ 85°C

安装类型

Surface Mount

封装/箱体

16-SOIC (0.295", 7.50mm Width)

类型

RS422, RS485

通道数

供应商器件封装

16-SOIC-IC

电压 - 电源

3.3V, 5V

数据速率

500kbps

电压 - 隔离

5000Vrms

通道类型

Unidirectional

上升/下降时间（典型值）

1.1µs, 1.1µs (Max)

隔离电源

Yes

输入 - 1 侧/2 侧

2/1

共模瞬变抗扰度（最小值）

25kV/µs

传播延迟 tpLH / tpHL （最大值）

700ns, 700ns

脉冲宽度失真（最大）

请求报价
