MT41K64M16TW-107:J Frequently Asked Questions (FAQs)


What is the maximum operating temperature range for this module?
The maximum operating temperature range for the MT41K64M16TW-107:J is 0°C to 95°C.


How do I ensure signal integrity on the address and command bus?
To ensure signal integrity on the address and command bus, use a controlled impedance PCB design, keep the signal traces short, and use a termination scheme such as ODT (On-Die Termination) or a discrete resistor.


What is the recommended refresh rate for this module?
The recommended refresh rate for the MT41K64M16TW-107:J is 8192 refreshes per second, with a refresh interval of 7.8us.


Can I use this module in a system with a different voltage supply?
The MT41K64M16TW-107:J is designed to operate at a voltage supply of 1.2V, but it can tolerate a voltage range of 1.14V to 1.26V. However, operating the module outside of its recommended voltage range may affect its performance and reliability.


How do I handle errors and retries in my system design?
Implement an error detection and correction mechanism, such as ECC (Error-Correcting Code) or CRC (Cyclic Redundancy Check), to detect and correct errors. Also, design a retry mechanism to handle errors that cannot be corrected.
