ADS1299IPAGR
IC AFE 8-CH 24BIT 64TQFP
型号
ADS1299IPAGR
制造商/品牌
系列
-
零件状态
Active
包装
Tape & Reel (TR)
封装/箱体
64-TQFP
通道数
8
供应商器件封装
64-TQFP (10x10)
位数
24
功率（瓦）
42mW
电压 - 电源，模拟
5V
电压 - 电源，数字
1.8 V ~ 3.6 V
