INA139NA/3K
IC CURRENT MONITOR 0.5% SOT23-5
型号
INA139NA/3K
制造商/品牌
系列
-
零件状态
Active
包装
Tape & Reel (TR)
工作温度
-40°C ~ 85°C
安装类型
Surface Mount
封装/箱体
SC-74A, SOT-753
电压 - 输入
2.7 V ~ 40 V
供应商器件封装
SOT-23-5
功能
Current Monitor
电流 - 输出
-
传感方法
High-Side
准确性
±0.5%
请求报价
