TL431ACDBZR
IC VREF SHUNT ADJ SOT23-3
型号
TL431ACDBZR
制造商/品牌
系列
-
零件状态
Active
包装
Tape & Reel (TR)
电流 - 供给
-
工作温度
0°C ~ 70°C (TA)
安装类型
Surface Mount
宽容
±1%
温度系数
-
封装/箱体
TO-236-3, SC-59, SOT-23-3
输出类型
Adjustable
电压 - 输入
-
供应商器件封装
SOT-23-3
电流 - 输出
100mA
引用类型
Shunt
电压 - 输出（最小/固定）
2.495V
电压 - 输出（最大）
36V
噪音 - 0.1Hz 至 10Hz
-
噪音 - 10Hz 至 10kHz
-
电流 - 阴极
600µA
