74HC164D
IC SHIFT REGISTER 8BIT 14SOP
型号
74HC164D
系列
74HC
零件状态
Active
包装
Tape & Reel (TR)
工作温度
-40°C ~ 125°C
安装类型
Surface Mount
封装/箱体
14-SOIC (0.154", 3.90mm Width)
输出类型
Push-Pull
供应商器件封装
14-SOP
元素数量
1
电压 - 电源
2 V ~ 6 V
功能
Serial to Parallel
逻辑类型
Shift Register
每个元素的位数
8
