FPF2700MPX
IC LOAD SWITCH CURR LIMIT 8-MLP
型号
FPF2700MPX
制造商/品牌
系列
AccuPower™
零件状态
Active
包装
Digi-Reel®
输入类型
Non-Inverting
工作温度
-40°C ~ 85°C (TA)
特征
Auto Restart, Power Good, Slew Rate Controlled, Status Flag
封装/箱体
8-WDFN Exposed Pad
输出类型
N-Channel
界面
On/Off
供应商器件封装
8-MLP (3x3)
电压 - 电源 (Vcc/Vdd)
Not Required
故障保护
Current Limiting (Adjustable), Over Temperature, UVLO
输出配置
High Side
导通电阻（典型值）
88 mOhm
电压 - 负载
2.8 V ~ 36 V
电流 - 输出（最大）
2A
输出数量
1
开关类型
General Purpose
比率 - 输入：输出
1:1
